XRotor PRO ESC (Dual Pack)

GREAT VALUE

This package comes with "2 ESCs"
SKU Product Name MSRP MAP
30902020 Xrotor PRO 25A-3D ESC $53.00 $35.98
30902005 Xrotor PRO 40A ESC $63.00 $43.98
30902004 Xrotor PRO 40A (COB) ESC * Popular $63.00 $43.98
30902003 Xrotor PRO 40A-3D ESC  * Popular $79.00 $53.98
30902010 Xrotor PRO 50A ESC $88.00 $59.98
30902015 Xrotor PRO 80A-HV ESC RTF Version Only $273.00 $159.50
SPECIFICATION
Model: XROTOR ESC
PRO 25A-3D PRO 40A
PRO 40A
(COB)
PRO 40A-3D
PRO 50A PRO 80A-HV
SKU 30902020 30902005 30902004 30902003 30902010 30902015
Cont./Peak Current
25A/40A 40A/60A 40A/60A 40A/60A 50A/70A 80A/100A
Input / 3-4S Lipo 3-6S Lipo 3-6S Lipo 3-6S Lipo 4-6S Lipo 4-12S Lipo
Bullet connector size Wire leaded w/ Connectors Φ3.5mmx3 Wire Leaded w/ Connectors Φ3.5mmx3 Connectors on Board Φ3.5mmx3 Wire Leaded w/ Connectors Φ3.5mmx3 Wire Leaded w/ Connectors Φ3.5mmx3 Wire Leaded
BEC Type / BEC Output NO NO NO NO NO NO
Programming item
NONE DEO
(ON/OFF)
DEO
(ON/OFF)
NONE LED ON/OFF status Color of the LED light ON/OFF of the DEO Motor rotation Timing
(High/Middle)
Size /
Weight
46.65x22.2x10.5
25g
66x21.8x11
50g
73.5x21.8x11
45g
73.5x21.8x11
45g
48 x 30 x 15.5
56g
77x35x21
106g

*DEO: Driving Efficiency Optimization
